An In-Depth Examination of Firefighting Shafts: Design, Integration, and Operational Resilience in High-Rise Structures

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

Abstract

Modern urbanisation has witnessed a substantial proliferation of high-rise and complex building typologies, necessitating increasingly sophisticated and robust fire safety strategies. Among the most critical of these strategies are firefighting shafts, meticulously engineered vertical pathways that serve as indispensable conduits for emergency response personnel and secure avenues for occupant evacuation during fire incidents. This comprehensive research report undertakes an exhaustive examination of firefighting shafts, delving into their fundamental design principles, intricate integration requirements with diverse building systems, adherence to international and regional regulatory standards, and the imperative maintenance protocols essential for their operational readiness. By methodically analysing these multifaceted aspects, this report endeavours to furnish a holistic and profound understanding of firefighting shafts, accentuating their pivotal role in fortifying building safety, enhancing emergency operational efficiency, and ultimately safeguarding human life and property in contemporary high-rise environments.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

1. Introduction

The exponential growth of high-rise buildings, defined as structures extending significantly above the ground level and presenting unique challenges for fire suppression and occupant egress, has become a defining characteristic of global urban landscapes. These towering structures concentrate large populations, present complex internal geometries, and often exceed the reach of standard ground-based firefighting equipment, thereby demanding advanced and highly resilient fire safety measures. The inherent risks associated with fire spread, smoke propagation, and the logistical challenges of vertical evacuation necessitate a multi-layered approach to fire protection engineering. Within this intricate framework, firefighting shafts – often interchangeably referred to as smokeproof enclosures, fire towers, or protected staircases in various jurisdictions – emerge as a cornerstone of vertical fire safety infrastructure.

Specifically designed as fortified vertical arteries, firefighting shafts are engineered to furnish a protected and smoke-free environment for firefighters to ascend to affected floors, deploy equipment, and establish command and control. Concurrently, they offer a secure and tenable egress route for building occupants, allowing them to evacuate safely downwards, away from the immediate hazard zone. The meticulous engineering of these shafts involves an acute understanding of fire dynamics, structural mechanics, and the intricate interplay of active and passive fire protection systems. Their primary function is to withstand the extreme temperatures, corrosive smoke, and structural stresses associated with a fire event, ensuring their integrity and functionality throughout the emergency. The effectiveness of a firefighting shaft is not merely determined by its structural robustness but also by its seamless integration with other critical building life safety systems, including but not limited to, smoke control, electrical supply, water supply for firefighting, and vertical transportation systems. This report explores these critical elements to underscore the indispensable contribution of firefighting shafts to the overall resilience and safety of high-rise constructions.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

2. Design Principles of Firefighting Shafts

The fundamental design of firefighting shafts is predicated upon creating a highly resilient and protected environment that can withstand severe fire conditions while maintaining its operational integrity. This involves rigorous attention to structural strength, material selection, spatial dimensions, and strategic placement within the building’s footprint.

2.1 Structural Integrity and Materials

The primary objective for the structural integrity of a firefighting shaft is to ensure its continued stability and functionality throughout a prescribed fire duration, even under the most adverse conditions. This necessitates the use of materials with inherently high fire resistance and robust construction methodologies. Common materials employed include reinforced concrete, masonry (brick or concrete block), and protected structural steel.

• Reinforced Concrete: Concrete is highly favoured due to its inherent non-combustibility, excellent thermal mass, and ability to resist fire for extended periods. The fire resistance of concrete elements depends on several factors, including the type of aggregate, concrete density, cover to reinforcement, and the cross-sectional dimensions of the member. For firefighting shafts, concrete walls are typically specified with a minimum thickness to achieve the required fire resistance rating, often 120 minutes (R 120, E 120, I 120 for load-bearing capacity, integrity, and insulation respectively, according to European standards, or equivalent ratings in other jurisdictions like two-hour fire rating in North America) and sometimes up to 240 minutes for very tall or complex structures. Designers must account for potential spalling of concrete under high temperatures, which can be mitigated through appropriate mix design, reinforcement detailing, and the use of fibres. (Eurocode 2: Design of concrete structures – Part 1-2: General rules – Structural fire design, EN 1992-1-2)
• Masonry: Brick or concrete block masonry, when properly constructed with appropriate mortar and thickness, can also provide significant fire resistance. Similar to concrete, the fire rating is dependent on wall thickness and material composition. Masonry offers good thermal insulation and is non-combustible.
• Protected Structural Steel: While steel is a strong structural material, its strength rapidly degrades at elevated temperatures typical in fires (above 550°C). Therefore, steel elements used in firefighting shafts must be adequately protected with fire-resistant coatings (e.g., intumescent paints, cementitious sprays), fire-resistant boards (e.g., mineral fibre, vermiculite), or concrete encasement. The protection system must ensure that the steel core temperature remains below critical levels for the required fire resistance period. (Eurocode 3: Design of steel structures – Part 1-2: General rules – Structural fire design, EN 1993-1-2)

Beyond material selection, the construction joints, penetrations for services, and connections must also maintain the specified fire resistance. Firestopping materials, such as intumescent seals, mineral wool, or silicone sealants, are critical to prevent the passage of smoke and flames through openings in fire-rated enclosures. The integrity of the shaft’s enclosure must achieve a fire resistance rating of at least 120 minutes, ensuring it remains intact and functional during a fire emergency. (Readkong, n.d.) This extends to all components forming the shaft, including floors, walls, and any internal structural elements.

2.2 Dimensions and Accessibility

The internal dimensions of firefighting shafts are critically important to ensure that they are genuinely functional during an emergency. The shaft must provide ample space for various operational requirements:

• Maneuvering Firefighting Equipment: This includes hoses, breathing apparatus sets, axes, thermal imaging cameras, and other specialised tools. Typically, a minimum clear width and depth (e.g., 1000mm to 1200mm for stair flights and landings, depending on jurisdiction and expected occupancy) are specified to allow firefighters, often wearing bulky equipment, to move freely without obstruction.
• Accommodating Personnel: The dimensions must facilitate the unhindered movement of multiple firefighters simultaneously, potentially carrying equipment, as well as enabling the safe evacuation of occupants. This also includes the ability to pass casualties on stretchers, requiring wider stair flights and landings than typical escape stairways. Minimum clear widths of 1100mm to 1200mm for stairways and landings are often mandated in codes, with larger dimensions preferred for very tall buildings or those with high occupant loads. (BS 9999:2017 Code of practice for fire safety in the design, management and use of buildings)
• Ventilation Openings: Firefighting shafts require effective smoke control to maintain a tenable environment. This is achieved through ventilation openings, typically in the form of automatic opening ventilators (AOVs) located at the top of the shaft and sometimes at each floor within a dedicated smoke lobby. These openings must be strategically sized and positioned to vent the entire compartment effectively. AOVs should activate automatically upon detection of smoke or heat, often via a fire alarm system, but also include manual override facilities for firefighters. The sizing of these vents is often determined through calculations based on the volume of the shaft and associated lobbies, or through advanced smoke modelling (e.g., CFD analysis). (Code Library, New York City Admin Code, n.d.) Natural smoke ventilation relies on buoyancy, while mechanical systems use fans to extract smoke or pressurise the shaft.

2.3 Firefighting Lobbies and Doors

Integral to the firefighting shaft system are fire lobbies, sometimes referred to as firefighting lobbies or protected lobbies. These are intermediate spaces located at each floor level, connecting the building’s occupied areas to the firefighting shaft. Their primary purpose is to act as a smoke buffer, preventing smoke from entering the shaft from the fire floor.

• Lobby Design: Fire lobbies typically have a minimum floor area (e.g., 6m² to 8m²) to allow firefighters to stage equipment and operate effectively. They must be constructed with the same fire resistance rating as the shaft itself and be clear of obstructions. They often contain the dry or wet riser outlet for firefighting hose connections.
• Fire Doors: The doors accessing the firefighting shaft from the fire lobby, and those between the fire floor and the fire lobby, are critical components. These must be fire-rated (e.g., FD60 or FD90, meaning 60 or 90 minutes of fire resistance), self-closing, and equipped with smoke seals to prevent smoke ingress. The doors should open in the direction of escape and be easily operable, even under duress. Vision panels within fire doors must also be fire-rated glass. The coordination between the door’s fire rating and the wall’s fire rating is crucial to ensure the overall integrity of the fire compartment.

2.4 Integration with Building Systems

For a firefighting shaft to function effectively as a life-safety critical system, it must be meticulously integrated with various other building systems. This integration is not merely about physical coexistence but about synergistic operation during a fire emergency. The design process must consider how HVAC, electrical, plumbing, and vertical transportation systems interact with and impact the shaft’s protected environment, particularly in maintaining smoke control, ensuring power supply, and facilitating water delivery. (ASHRAE Handbook, n.d.) The complexity of this integration increases exponentially with building height and functional diversity, requiring sophisticated control logic and robust fail-safe mechanisms.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

3. Integration Challenges with Building Systems

The seamless integration of firefighting shafts with other essential building systems represents one of the most significant challenges in high-rise fire safety engineering. A holistic design approach is imperative to ensure that these systems do not compromise the shaft’s integrity or functionality during an emergency. This requires detailed coordination among architects, structural engineers, fire engineers, and mechanical, electrical, and plumbing (MEP) consultants.

3.1 HVAC Systems and Smoke Control

The management of smoke is paramount in firefighting shafts. Smoke is the leading cause of fatalities in building fires, and its uncontrolled spread can render evacuation routes untenable and hinder firefighting operations. HVAC systems play a critical role in smoke control, but their integration presents complex challenges, particularly concerning stairwell pressurisation and mechanical smoke extraction. (Readkong, n.d.; IFP Magazine, n.d.)

3.1.1 Stairwell Pressurisation Systems

Stairwell pressurisation systems are active smoke control measures designed to prevent smoke infiltration into stairwells and firefighting lobbies by maintaining a higher air pressure within these protected spaces than in adjacent fire-affected areas.

• Principle of Operation: Fans introduce fresh air into the stairwell, creating a pressure differential that pushes smoke away from the protected enclosure. This ensures a clear, breathable atmosphere for evacuees and firefighters.
• Components: Key components include dedicated pressurisation fans (often located at the top of the shaft or in a dedicated plant room), a network of ducts and grilles to distribute air evenly, pressure sensors to monitor the differential pressure, automatic dampers to control airflow, and a control panel interfaced with the building’s fire alarm system.
• Control Strategies: The system must activate automatically upon fire alarm detection. It typically maintains a positive pressure differential (e.g., 50 Pascals to 100 Pascals) between the stairwell and the building interior. Challenges arise from dynamic conditions such as open doors (which can cause pressure loss and reverse airflow), the ‘stack effect’ (natural airflow due to temperature differences between inside and outside air in tall buildings), and wind effects on building facades. To counteract these, advanced systems may incorporate variable speed drives for fans, pressure relief dampers (barometric or motorised) to prevent excessive pressure that could impede door opening, and sophisticated control logic that adjusts fan speed based on pressure sensor feedback. (ASHRAE Handbook, n.d.)
• Testing and Commissioning: Rigorous testing and commissioning are crucial to verify system performance under various door opening scenarios (e.g., single door open, multiple doors open). Regular maintenance and periodic re-testing (e.g., annually) are essential to ensure continued operational readiness. (BS EN 12101-6: Smoke and heat control systems – Part 6: Specification for pressure differential systems – Kits)

3.1.2 Mechanical Smoke Extraction Systems from Lobbies

An alternative or supplementary approach involves mechanically extracting smoke from the firefighting lobbies before it can enter the stairwell.

• Principle of Operation: Exhaust fans remove smoke from the lobby, drawing fresh air into the lobby from the fire floor or a dedicated air supply. This creates a negative pressure relative to the fire floor, effectively containing smoke within the lobby.
• Design Considerations: The design must ensure adequate air supply to the lobby to prevent the system from going into negative pressure relative to the stairwell. Factors such as the size of the lobby, the expected smoke volume, and the building’s overall ventilation strategy influence fan sizing and ductwork layout. Often, the extracted smoke is routed through dedicated smoke shafts or ducts to the outside, typically above the roof level.
• Hybrid Systems: Many modern high-rise buildings employ hybrid smoke control systems that combine stairwell pressurisation with mechanical smoke extraction from lobbies, offering enhanced protection and redundancy. Computational Fluid Dynamics (CFD) modelling is increasingly used in complex building geometries to simulate smoke movement and optimise the design of smoke control systems, ensuring their effectiveness under various fire scenarios.

3.2 Electrical Systems

The reliability of electrical systems within and serving firefighting shafts is paramount. Critical systems, including firefighting lifts, smoke control fans, emergency lighting, fire alarm systems, and communication equipment, must remain operational during a power outage or fire.

• Emergency Power Supply: Firefighting shafts and their associated systems require an independent and reliable emergency power supply, typically from a dedicated generator set or an uninterruptible power supply (UPS) system. This ensures that essential life safety systems continue to function even if the main building power is compromised. The transition to emergency power must be automatic and rapid.
• Circuit Integrity: Electrical circuits serving fire safety equipment within the shaft and lobbies must have enhanced circuit integrity to withstand fire exposure for the specified duration (e.g., 120 minutes). This is achieved through fire-rated cabling (e.g., mineral insulated copper cable (MICC), FP200 Gold, or equivalent fire-resistant cables), which are designed to maintain electrical continuity even when directly exposed to flames. Cables must be routed through protected routes or within the fire-rated shaft structure itself. (BS 8519:2020 Selection and installation of fire-resistant power and control cable systems for life safety and fire fighting applications – Code of practice)
• Segregation and Protection: Electrical wiring and equipment within the shaft must be segregated from other building services where possible, to prevent damage or short circuits from impacting non-essential systems. Electrical panels and controls for the shaft’s systems should be located in fire-rated enclosures or secure areas accessible to firefighters.
• Emergency Lighting: The firefighting shaft, lobbies, and associated exit routes must be equipped with emergency lighting that activates automatically upon power failure, providing sufficient illumination for safe egress and firefighting operations. This lighting must also be served by fire-rated circuits.

3.3 Plumbing Systems (Firefighting Risers)

Firefighting shafts are incomplete without readily accessible and reliable water supply for firefighting. This is primarily provided through standpipe systems, commonly known as wet or dry risers.

• Dry Risers: In buildings of moderate height, dry risers are often installed. These are empty pipes that extend vertically through the building, with inlets at ground level for fire service connection and outlets (landing valves) at each floor level within the firefighting lobby. Firefighters connect their hoses to the landing valves, and a fire appliance at ground level pumps water into the system. Dry risers require periodic testing (e.g., annually) to ensure they are free from blockages and leaks. (BS 9990:2015 Non-automatic fire-fighting systems in buildings – Code of practice)
• Wet Risers: For taller buildings, wet risers are mandatory. These systems are permanently charged with water from a dedicated tank and pump system, maintaining constant pressure. This allows firefighters immediate access to water without the delay of connecting to a ground-level pump. Wet risers offer greater immediate utility and flow consistency. They require robust pumps (often with duty and standby configurations and emergency power supply), water storage tanks, and pressure-regulating valves at various levels to ensure adequate pressure at all outlets. (NFPA 14: Standard for the Installation of Standpipe and Hose Systems)
• Material and Protection: Both wet and dry risers must be constructed from fire-resistant materials (e.g., steel pipework) and adequately supported within the firefighting shaft. They must be protected from mechanical damage and freezing temperatures. Outlets must be easily accessible within the fire lobby, away from the immediate door swing, and at a convenient height for hose connection.
• Domestic Water Systems: While not directly part of the firefighting system, domestic plumbing systems within the building must be designed such that their failure during a fire does not compromise the firefighting shaft or its services. Pipes passing through the shaft’s fire-rated enclosure must be appropriately firestopped.

3.4 Lift Systems (Firefighting Lifts)

Firefighting lifts are an indispensable component of modern firefighting shafts in high-rise buildings, providing a protected means of vertical transportation for firefighters and their equipment. They are distinctly different from standard passenger lifts and are designed for operation under fire conditions. (DesignHorizons, n.d.)

• Design and Operation: Firefighting lifts are robustly constructed, with enhanced fire resistance for the lift car, shaft enclosure, and machine room. They must be served by an emergency power supply, enabling them to operate even if the main power fails. A key feature is the ‘fire service override’ control, which allows firefighters to take sole control of the lift, bypassing normal passenger controls and call functions. This allows them to travel directly to the fire floor or a specified floor, preventing the lift from opening on a fire-affected level.
• Performance Requirements: Firefighting lifts typically have higher speeds and greater carrying capacity than standard lifts to transport firefighters and their heavy equipment efficiently. The lift car must be of sufficient size to accommodate a stretcher (e.g., 2000mm x 1100mm) and multiple firefighters. They must be designed to withstand water ingress from hoses and have robust communication systems within the car.
• Protected Lobbies: Similar to the staircase, firefighting lifts terminate into fire-rated lobbies at each floor, which serve as protected areas for firefighters to exit the lift safely and access the fire floor. These lobbies are typically integrated with the overall smoke control system, often utilising pressurisation.
• Shaft Enclosure: The lift shaft itself must have the same fire resistance rating as the firefighting stair shaft, ensuring that the protected travel path is maintained. Penetrations for lift cables and services must be firestopped effectively.
• Evacuation Lifts: In increasingly taller buildings, the concept of ‘Evacuation Lifts’ is emerging. These lifts are designed to be used by occupants for safe evacuation during a fire, under controlled conditions. They have even higher safety specifications and often require dedicated fire-rated lobbies and robust management systems to ensure controlled, phased evacuation. While not purely firefighting shafts, they share many design principles regarding protection and reliability.

3.5 Communication Systems

Effective communication within the firefighting shaft and between firefighters, the fire command centre, and external emergency services is vital.

• Emergency Voice Communication (EVC) Systems: These systems (also known as ‘firefighter telephones’ or ‘refuge area systems’) allow two-way communication between the fire command centre and various points within the building, including the firefighting lobbies at each floor. This enables firefighters to report conditions, request resources, and receive instructions.
• Radio Enhancement Systems (DAS): In large or complex high-rise buildings, standard two-way radios may not function reliably due to signal attenuation. Distributed Antenna Systems (DAS) are installed to enhance radio signals within the building, particularly in core areas like firefighting shafts, ensuring seamless communication for emergency responders. These systems are typically required for specific public safety radio frequencies.

3.6 Building Management Systems (BMS) and Fire Command Centres

The effective operation of all integrated systems – smoke control, lifts, electrical power, and communications – relies heavily on the building’s overall control infrastructure.

• Centralised Control: A dedicated fire command centre (or fire control room) serves as the nerve centre during an emergency. It houses the fire alarm control panel, mimic diagrams of the building, controls for smoke management systems, CCTV monitors, public address systems, and communication links to emergency services.
• Interoperability: The BMS must be programmed to automatically initiate predefined fire safety sequences upon activation of the fire alarm. This includes activating smoke control systems, recalling lifts to designated floors, unlocking emergency exits, and shutting down non-essential HVAC systems. The interface must be intuitive for emergency responders, allowing them to monitor system status and manually override controls if necessary. The complexity of these integrated systems underscores the necessity of interdisciplinary collaboration from the earliest stages of building design. (LWF.co.uk, Part 48, 2020)

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

4. International Variations in Standards

Firefighting shaft standards and associated fire safety regulations exhibit significant variations across different countries and regions. These differences stem from diverse building codes, historical fire events, cultural approaches to risk, technological advancements, and varying climate conditions. Understanding and adhering to local regulatory frameworks is paramount for the design and implementation of effective firefighting shafts.

4.1 United Kingdom Standards

In the UK, fire safety design for buildings is governed by a combination of prescriptive guidance documents (e.g., Approved Document B for England and Wales), British Standards (BS), and increasingly, performance-based fire engineering.

• Approved Document B (ADB): This guidance document provides minimum acceptable standards for fire safety in new and altered buildings. It outlines requirements for protected escape routes, fire resistance periods for structural elements, and provisions for firefighting access. For tall buildings, ADB often directs designers towards fire engineering solutions or more stringent standards.
• BS 9999:2017 – Code of practice for fire safety in the design, management and use of buildings: This comprehensive standard offers a risk-based approach to fire safety. It details requirements for firefighting shafts, including their dimensions, fire resistance, smoke control, and the provision of firefighting lifts. For instance, it specifies minimum dimensions for firefighting stairs (e.g., clear width of 1100mm) and lobbies, and robust requirements for fire-resisting construction and fire doors. It also outlines criteria for smoke control systems, including stair pressurisation and mechanical smoke extraction, often referencing BS EN 12101 series for detailed specifications. (British Standard BS 9999:2017)
• BS 5588-5:1991 – Fire precautions in the design, construction and use of buildings – Part 5: Code of practice for firefighting lifts: While a slightly older standard, it provides detailed guidelines on the design, construction, and use of firefighting lifts, including specifications for lift cars, wells, machine rooms, and control systems. It emphasises the need for independent power supplies and firefighter override controls. (Intertek, n.d.) More recent guidance may refer to BS EN 81-72:2020 (Safety rules for the construction and installation of lifts – Particular applications for passenger and goods passenger lifts – Part 72: Firefighter lifts), which aligns with European standards.
• BS 8519:2020 – Selection and installation of fire-resistant power and control cable systems for life safety and fire fighting applications – Code of practice: This standard provides detailed guidance on the fire resistance requirements for cables supplying essential life safety and firefighting equipment, categorising cables by their fire performance and specifying installation methods.

4.2 United States Standards

In the U.S., fire safety is primarily governed by model building codes developed by organisations like the International Code Council (ICC) and fire codes developed by the National Fire Protection Association (NFPA).

• International Building Code (IBC): The IBC, adopted by most U.S. states and many other countries, includes comprehensive provisions for fire-resistance-rated construction, means of egress, and active fire protection systems. It specifies requirements for exit stairways, which, when designed as fire towers or smokeproof enclosures, function as firefighting shafts. The IBC mandates specific fire-resistance ratings for these enclosures (e.g., 2-hour rating for buildings 4 stories or more, 3-hour rating for high-rise buildings defined as 75 feet or more in height). It details requirements for vestibules (lobbies) for smokeproof enclosures and mechanical ventilation systems to maintain smoke-free conditions. (International Building Code, 2024 Edition)
• NFPA 101: Life Safety Code: This code focuses on occupant safety from fire and related emergencies. It provides criteria for stairways and other egress components, including requirements for protected shafts and their enclosures, emergency lighting, and exit signage.
• NFPA 92: Standard for Smoke Control Systems: This standard details the design, installation, acceptance testing, and maintenance of smoke control systems, including stairwell pressurisation and mechanical smoke exhaust systems, which are integral to firefighting shafts. It provides specific performance criteria for pressure differentials and airflow rates.
• NFPA 14: Standard for the Installation of Standpipe and Hose Systems: This standard governs the design and installation of wet and dry risers, including their components, water supply requirements, and pressure demands, ensuring firefighters have adequate water access within tall buildings.

4.3 European Standards (Eurocodes & EN Series)

European standards are moving towards harmonised Eurocodes for structural design and EN (European Norm) series for product and system standards, providing a common framework across member states.

• Eurocodes (e.g., EN 1991-1-2, EN 1992-1-2, EN 1993-1-2): These codes provide rules for the structural design of buildings in fire conditions, specifying how to determine the fire resistance of concrete, steel, and timber elements. They are crucial for ensuring the structural integrity of firefighting shafts.
• EN 12101 Series (Smoke and Heat Control Systems): This series is particularly relevant for active smoke control:
  • EN 12101-2: Specifies requirements for natural smoke and heat exhaust ventilators (AOVs).
  • EN 12101-6: Details specifications for pressure differential systems (stairwell pressurisation kits), including performance criteria, calculation methods, and testing procedures.
  • EN 12101-7: Deals with smoke duct sections.
  • EN 12101-8: Covers smoke dampers.
• EN 81-72:2020 – Safety rules for the construction and installation of lifts – Particular applications for passenger and goods passenger lifts – Part 72: Firefighter lifts: This is the primary European standard for the design, construction, and operation of firefighter lifts, aligning with the BS 5588-5 where applicable.
• EN 1634 Series (Fire resistance and smoke control tests for door and shutter assemblies, openable windows and building hardware elements): This series provides test methods and classification for fire doors and hardware components, critical for maintaining the integrity of fire lobbies.

4.4 Asian Standards (e.g., Vietnam, Singapore, Hong Kong)

Many Asian countries have developed their own comprehensive fire safety codes, often drawing inspiration from international best practices while adapting to local conditions.

• Vietnam: The National Technical Regulations on fire safety for buildings in Vietnam (e.g., Circular 01/2020/TT-BXD) specify detailed requirements for fire resistance, means of escape, and firefighting provisions. These regulations often include minimum water flow rates for firefighting (e.g., for wet risers), with adjustments based on building materials and fire-resistance categories. They also define requirements for fire compartments, protected staircases, and smoke control systems. (vanbanphapluat.co, n.d.)
• Singapore: The Singapore Civil Defence Force (SCDF) Fire Code is comprehensive, mandating specific requirements for protected staircases, fire lift provisions, and pressurisation systems. It specifies clear widths, fire resistance periods (e.g., 2-4 hours), and requirements for fire-rated doors and lobbies. It also has stringent requirements for external firefighting provisions and access for fire appliances.
• Hong Kong: The Fire Services Department and Buildings Department enforce strict fire safety regulations. These include detailed requirements for protected lobbies and staircases, often referred to as ‘protected means of escape,’ with specific fire resistance ratings, ventilation requirements (natural or mechanical), and the provision of fire service installations like wet risers and fire lifts. The emphasis is on providing safe routes for occupants and clear access for firefighters.

These international variations underscore the critical importance for fire safety engineers, architects, and developers to be thoroughly conversant with the specific building codes, local amendments, and performance-based design guidelines applicable to their project’s jurisdiction. Cross-jurisdictional collaboration and the adoption of best practices, while adhering to local mandates, are essential for achieving optimal fire safety in global high-rise construction.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

5. Maintenance Protocols and Operational Readiness

The most meticulously designed firefighting shaft is only as effective as its operational readiness, which is directly dependent on robust maintenance protocols, rigorous testing, and comprehensive training. These elements ensure that all components of the shaft system function as intended during an emergency.

5.1 Routine Inspection and Testing

Regular and systematic inspection and testing are fundamental to ensuring the long-term reliability and functionality of firefighting shafts and their integrated systems. A structured maintenance schedule, typically encompassing daily, weekly, monthly, quarterly, and annual checks, is essential.

• Daily/Weekly Checks: These often involve visual inspections by building management or security personnel. Checks should include ensuring all fire doors accessing the shaft are unobstructed, self-closing correctly, and free from damage. Emergency lighting within the shaft should be visually checked for functionality. Exit signage should be clear and illuminated. (LWF.co.uk, Part 48, 2020)
• Monthly Checks: More detailed checks should be performed monthly. This includes testing the operation of automatic opening ventilators (AOVs) for smoke control systems, verifying that they open and close properly. Firefighting lift functionality should be checked, including the fire service override control. Communication devices, such as firefighter telephones, should be tested for clear audio transmission and reception.
• Quarterly Checks: A qualified technician should conduct comprehensive checks of smoke control systems, including stairwell pressurisation fans, associated ductwork, dampers, and pressure sensors. This includes checking motor functionality, belt tension, and overall system integrity. Wet and dry riser systems should be visually inspected for leaks, damage, and clear access to connections.
• Annual and Biennial Testing: Annual testing is critical for all active fire safety systems.
  • Smoke Control Systems: Full operational testing of the entire smoke control system, simulating fire alarm activation and verifying pressure differentials and airflow rates. This should involve opening doors at various levels to simulate real-world conditions. For pressurisation systems, this includes checking door opening forces to ensure they do not exceed regulatory limits (e.g., 133N or 30 lbf as per NFPA 101).
  • Firefighting Lifts: Comprehensive annual testing of firefighting lifts, including all operational modes, safety devices, emergency power transfer, and communication systems. (BS 9999:2017; NFPA 25: Standard for the Inspection, Testing, and Maintenance of Water-Based Fire Protection Systems)
  • Wet/Dry Risers: Annual flow and pressure testing for wet risers to ensure adequate water delivery at all outlets. Dry risers require annual pressure testing with water to check for leaks and blockages, and typically a visual inspection every six months.
  • Electrical Systems: Annual testing of emergency lighting batteries, generator sets (load testing), and fire-rated circuit integrity where practicable.
• Five-Yearly Comprehensive Overhaul: Some systems, like wet risers, may require a more thorough internal inspection and hydrostatic testing every five years to detect hidden corrosion or damage. Similarly, firefighting lifts may undergo more extensive overhauls.

All identified issues during inspections and testing must be promptly documented, reported, and addressed by qualified personnel. A robust logbook or digital record-keeping system must be maintained, detailing all maintenance activities, test results, and corrective actions taken. This documentation is crucial for compliance, auditing, and demonstrating due diligence.

5.2 Training and Drills

Beyond technical maintenance, the human element plays a crucial role in the effective utilisation of firefighting shafts. Comprehensive training and regular drills are essential for both building occupants and emergency responders.

• Training for Building Occupants:
  • Fire Safety Awareness: Occupants must be educated on the location of firefighting shafts, the purpose of fire lobbies, and the importance of keeping these areas clear of obstructions.
  • Evacuation Procedures: Regular fire drills familiarise occupants with evacuation routes, including the proper use of stairwells and the safe assembly points outside the building. While firefighting lifts are primarily for fire service use, general lifts may be used for evacuation in certain circumstances (Evacuation Lifts), and occupants must understand their role in such scenarios. Building occupants should be trained not to use firefighting lifts unless directed to do so by emergency personnel in an evacuation lift scenario.
  • Reporting Fires: Training should include how to correctly report a fire, activate the fire alarm, and respond to alarm signals.
• Training for Emergency Personnel (Fire Services):
  • Familiarisation with Building Layout: Fire services personnel need to be intimately familiar with the layout of high-rise buildings in their jurisdiction, particularly the location and features of firefighting shafts, fire control rooms, and access points for fire apparatus. Regular site visits and pre-incident planning sessions are crucial.
  • Operational Procedures: Training should cover the specific procedures for using firefighting lifts (including override controls), connecting to wet/dry risers, operating smoke control systems from the fire command centre, and using communication systems within the shaft.
  • Scenario-Based Drills: Joint drills between building management/fire wardens and local fire services, simulating various fire scenarios, are invaluable. These drills help to identify potential weaknesses in procedures or systems, improve coordination, and enhance the efficiency and safety of responders during actual incidents. They can also test the full activation sequence of integrated systems under realistic pressures. (DesignHorizons, n.d.)
  • Equipment Familiarisation: Firefighters must be familiar with the types of equipment found in firefighting shafts, such as the specific couplings for standpipes, the controls for AOV systems, and the user interface of the fire command panel.

5.3 Role of Technology in Maintenance and Readiness

Advanced building management systems (BMS), the Internet of Things (IoT), and smart sensors are increasingly enhancing the maintenance and operational readiness of firefighting shafts.

• Predictive Maintenance: IoT sensors can continuously monitor the performance of fans, pumps, and other critical equipment, collecting data on operational parameters like vibration, temperature, and current draw. This allows for predictive maintenance, identifying potential failures before they occur, reducing downtime, and ensuring higher reliability.
• Remote Monitoring: BMS can allow for remote monitoring of firefighting shaft systems, providing real-time status updates and alerts to building managers and, in some cases, to fire authorities, enhancing response capabilities.
• Digital Twins: The creation of digital twins of high-rise buildings, including their fire safety systems, allows for virtual simulation of fire scenarios and testing of system responses, aiding in optimisation and training without disrupting building operations.

The commitment to a rigorous maintenance schedule, coupled with comprehensive training and leveraging technological advancements, is non-negotiable for ensuring that firefighting shafts remain fully operational and effective life-saving assets throughout the lifespan of a high-rise building.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

6. Emerging Trends and Future Directions in Firefighting Shaft Design

As building designs become more ambitious and climate change introduces new environmental considerations, the evolution of firefighting shaft design and associated fire safety strategies continues. Several emerging trends and future directions are shaping the next generation of high-rise fire protection.

6.1 Performance-Based Design (PBD)

Traditionally, fire safety design has relied heavily on prescriptive codes, which mandate specific dimensions, material fire ratings, and system types. While effective, prescriptive codes can sometimes stifle innovation and may not always be the most optimal solution for highly complex or unique building designs. Performance-based design (PBD) offers a more flexible and often more robust approach.

• Principles: PBD focuses on achieving specific fire safety objectives (e.g., tenable conditions for evacuation for a certain duration, safe access for firefighters) rather than strictly adhering to prescriptive requirements. It involves detailed fire engineering analysis, often utilising advanced computational tools like Computational Fluid Dynamics (CFD) for smoke modelling and evacuation simulation software. (SFPE Handbook of Fire Protection Engineering, 6th Edition)
• Application to Firefighting Shafts: For firefighting shafts, PBD can justify alternative smoke control strategies, optimise AOV sizing, or demonstrate the effectiveness of novel material applications, provided that the desired safety outcomes are rigorously proven. This allows for tailored solutions that consider the building’s specific occupancy, geometry, and operational characteristics, potentially leading to more efficient and cost-effective designs while maintaining or enhancing safety levels.

6.2 Enhanced Resilience and Redundancy

Future designs will increasingly emphasise enhanced resilience and redundancy in critical life safety systems, including those associated with firefighting shafts.

• System Hardening: This involves designing systems to withstand a wider range of potential failures, including natural disasters (earthquakes, extreme weather) and targeted attacks. This might include physical protection of critical equipment (e.g., pumps, generators, control panels) and diversified routing of services.
• Redundant Systems: Incorporating duplicate or alternative systems (e.g., multiple smoke control fans on separate power circuits, dual wet risers, or multiple independent firefighting lifts) ensures that a single point of failure does not compromise the entire safety system. The concept of ‘graceful degradation,’ where systems continue to function at a reduced capacity rather than failing entirely, will become more prevalent.

6.3 Smart Building Technologies and IoT Integration

The ongoing revolution in smart building technologies and the Internet of Things (IoT) offers unprecedented opportunities for dynamic fire safety management.

• Real-time Monitoring and Adaptive Control: Networks of smart sensors (smoke, heat, air quality, pressure) can provide real-time data on fire conditions, smoke movement, and system performance within and around the firefighting shaft. This data can feed into AI-powered building management systems that can dynamically adjust smoke control strategies (e.g., fan speeds, damper positions) in response to evolving fire scenarios, optimising conditions for both evacuation and firefighting.
• Predictive Analytics: AI and machine learning algorithms can analyse historical data from drills and incidents, combined with real-time sensor inputs, to predict fire behaviour and potential system failures, enabling proactive maintenance and more effective emergency responses.
• Digital Twins: The development of detailed digital twins of buildings allows for virtual simulation of fire incidents, providing firefighters with real-time actionable intelligence on smoke spread, structural integrity, and the operational status of safety systems before and during an incident.

6.4 Sustainable Fire Safety Design

As sustainability becomes a central pillar of building design, fire safety systems, including firefighting shafts, are also being viewed through an environmental lens.

• Energy Efficiency: Optimising the energy consumption of smoke control fans and other active systems through efficient motor technology, intelligent controls, and potentially leveraging natural ventilation where appropriate.
• Sustainable Materials: Using environmentally friendly, recycled, or locally sourced materials for the construction of shafts, provided they meet the stringent fire resistance requirements. This includes considering the embodied carbon of fire protection materials.
• Integration with Green Building Certifications: Ensuring that fire safety designs, while prioritising life safety, also contribute positively to green building certification schemes (e.g., LEED, BREEAM).

6.5 Vertical Evacuation Challenges in Megatall Buildings

For future megatall buildings (600m+), conventional evacuation methods using stairwells become increasingly impractical due to travel distance and endurance limits. Firefighting shafts will evolve to accommodate this challenge.

• Enhanced Evacuation Lifts: The concept of dedicated, fire-protected ‘evacuation lifts’ will become more prominent, serving as the primary means of vertical evacuation for occupants, complementing or even superseding stairways in ultra-tall structures. These lifts will require even higher levels of redundancy, fire resistance, and advanced control systems.
• Sky Lobbies and Refuge Areas: Firefighting shafts will integrate more closely with multi-level sky lobbies and designated refuge areas, providing secure transfer points and temporary safe havens during phased evacuation strategies. These areas will require their own robust fire and smoke protection.

The future of firefighting shafts lies in their continuous evolution to meet the challenges posed by increasingly complex and taller buildings. This will involve a deeper integration of smart technologies, a greater reliance on performance-based fire engineering, and a holistic approach to building resilience that considers both human safety and environmental impact.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

7. Conclusion

Firefighting shafts stand as undeniably vital components within the intricate fire safety infrastructure of high-rise buildings. They represent much more than mere vertical passages; they are meticulously engineered lifelines that provide secure and tenable pathways for emergency responders to effectively combat fires and, crucially, offer safe and protected evacuation routes for building occupants. The effectiveness of these critical elements hinges upon a confluence of fundamental design principles, seamless integration with disparate building systems, unwavering adherence to stringent international and national standards, and the rigorous application of comprehensive maintenance protocols.

From the selection of fire-resistant structural materials like robust reinforced concrete and protected steel, to the precise sizing and placement of fire lobbies and automatic opening ventilators, every aspect of a firefighting shaft’s design is dictated by the imperative to withstand the most extreme conditions of a fire incident. The challenges of integrating these shafts with active building systems – notably complex HVAC-driven smoke control systems, resilient electrical supplies, high-pressure wet/dry risers, and indispensable firefighting lifts – demand exceptional interdisciplinary coordination and advanced engineering solutions to ensure their synergistic operation during an emergency. Furthermore, the global landscape of building codes and fire safety regulations necessitates a nuanced understanding of varying jurisdictional requirements, highlighting the importance of localised compliance while embracing international best practices.

Crucially, the inherent safety promise of a firefighting shaft is realised only through a steadfast commitment to its ongoing operational readiness. This mandates systematic routine inspection, meticulous testing of all integrated components, and regular, realistic training drills for both building occupants and emergency services personnel. The advent of smart building technologies and the adoption of performance-based design methodologies are poised to further enhance the resilience and responsiveness of these critical safety assets, addressing emerging challenges in an increasingly urbanised and complex built environment.

In essence, firefighting shafts are not static architectural features but dynamic, living systems requiring continuous attention throughout a building’s lifecycle. Their sustained reliability is a testament to sophisticated engineering, stringent regulation, and diligent management. Ongoing research, technological innovation, and a proactive approach to their design, maintenance, and integration are unequivocally necessary to continually elevate the safety and resilience of high-rise buildings, thereby safeguarding communities and bolstering urban preparedness against the ever-present threat of fire.

Many thanks to our sponsor Focus 360 Energy who helped us prepare this research report.

References

• ASHRAE Handbook. (n.d.). CHAPTER 53. FIRE AND SMOKE CONTROL. Retrieved from handbook.ashrae.org
• British Standards Institution. (2017). BS 9999: Code of practice for fire safety in the design, management and use of buildings. BSI.
• British Standards Institution. (2020). BS 8519: Selection and installation of fire-resistant power and control cable systems for life safety and fire fighting applications – Code of practice. BSI.
• British Standards Institution. (2015). BS 9990: Non-automatic fire-fighting systems in buildings – Code of practice. BSI.
• British Standards Institution. (n.d.). BS EN 12101-6: Smoke and heat control systems – Part 6: Specification for pressure differential systems – Kits. BSI.
• British Standards Institution. (n.d.). BS EN 81-72:2020 Safety rules for the construction and installation of lifts – Particular applications for passenger and goods passenger lifts – Part 72: Firefighter lifts. BSI.
• Code Library, New York City Admin Code. (n.d.). REFERENCE STANDARD RS 5 – 17 STANDARDS FOR THE INSTALLATION OF SMOKE SHAFTS. Retrieved from codelibrary.amlegal.com
• DesignHorizons. (n.d.). Firefighting Lift Design and Operational Standards. Retrieved from designhorizons.org
• European Committee for Standardization. (n.d.). EN 1992-1-2: Eurocode 2: Design of concrete structures – Part 1-2: General rules – Structural fire design.
• European Committee for Standardization. (n.d.). EN 1993-1-2: Eurocode 3: Design of steel structures – Part 1-2: General rules – Structural fire design.
• International Fire Protection Magazine. (n.d.). Smoke Shafts – The Solution for Smoke Control in High Rise Buildings. Retrieved from ifpmag.com
• International Code Council. (2024). International Building Code (IBC).
• Intertek. (n.d.). BS 5588-5:1991 Fire precautions in the design, construction and use of buildings. Retrieved from intertekinform.com
• Lawrence Webster Forrest. (2020, January 16). Fire Engineering Design and Risk Assessment – Firefighting Shafts – Part 48. Retrieved from lwf.co.uk
• National Fire Protection Association. (n.d.). NFPA 14: Standard for the Installation of Standpipe and Hose Systems. NFPA.
• National Fire Protection Association. (n.d.). NFPA 25: Standard for the Inspection, Testing, and Maintenance of Water-Based Fire Protection Systems. NFPA.
• National Fire Protection Association. (n.d.). NFPA 92: Standard for Smoke Control Systems. NFPA.
• National Fire Protection Association. (n.d.). NFPA 101: Life Safety Code. NFPA.
• Readkong. (n.d.). Firefighting Shafts in Taller Buildings – Designer’s Guide to Firefighting Operations. Retrieved from readkong.com
• Society of Fire Protection Engineers. (n.d.). SFPE Handbook of Fire Protection Engineering (6th Edition).
• vanbanphapluat.co. (n.d.). Circular 01/2020/TT-BXD Issuance of National Technical Regulations on Fire Safety for Buildings. Retrieved from vanbanphapluat.co
